Panel
Panel
4-side Ultra Thin, In-Plane Switching
Max View Area
- Active Area: 697.3 x 392.2 mm
- Screen Dimension: 709.4 x 408.4 mm
Pixel Pitch
0.1816 x 0.1816 mm
Dot / Pixel Per Inch
140 dpi
Contrast Ratio
- Contrast Ratio (Typical): 1500:1
- Dynamic Contrast Ratio (Typical): 3000000:1
View Angle (H / V)
Horizontal: 178°, Vertical: 178°
Response Time
- Extreme Mode: 4 ms
- Normal Mode: 6 ms
Color Gamut
- Coverage Ratio: 99% sRGB (CIE 1931)
- Coverage Ratio: 99% BT.709 (CIE 1931)
Color Support
1.07 Billion
Color Depth
10-bit (8-bit+FRC)
Screen Surface Treatment
Anti-glare
Operating System
Operating System
- Windows® 11 Support
- Windows® 10 Support
Multi-Media
Camera
- ThinkVision® VoIP Stack MC60 monitor webcam (For models 64B0ZAT1 and 64B0ZAR1)
- No bundled webcam (Support ThinkVision® VoIP Stack MC60 Monitor Webcam, sold separately)
Speakers
No Sperakers (Support MS30 Monitor Soundbar, sold separately)
Power Supply
Power Consumption
- Typical / Max: 25.5W / 195W
- Sleep / Off mode: <0.5W
- Switch-off Mode: <0.3W
- Energy Star Power On: 25.2W
- Energy Star TEC: 102.8kWh
- Internal Power Supply
Voltage Required
AC 100 to 240 V (50-60Hz)
Special Features
Special Features
- HDR10 Compliance
- Lenovo® ThinkColour (Lenovo® Accessories and Display Manager) Support
Lenovo® ThinkColour supports Windows® 10 & 11, Mac OS (functions vary across systems).
Lenovo® Accessories and Display Manager is formerly Lenovo® Display Control Center.
- LDFM (Lenovo® Display Fleet Manager)
- Mirrored Power Button
- Natural Low Blue Light
- Smart Power
Mechanical
ThinkCentre® M Series Support
To support Tiny devices, an additional ThinkCentre® Tiny Mounting Kit (PN:4XF1R07369) is required (sold separately).
Bezel Width
- Side: 2.0mm
- Top: 2.0mm
- Bottom: 11.4mm
Dimensions (WxDxH)[1]
| Head Only | 714.2 x 46.5 x 413.0 mm (28.12 x 1.83 x 16.26 inches) |
| Highest Position | 714.2 x 218.0 x 594.3 mm (28.12 x 8.58 x 23.40 inches) |
| Lowest Position | 714.2 x 218.0 x 439.3 mm (28.12 x 8.58 x 17.30 inches) |
Packaging Dimensions (WxDxH)
950.0 x 139.0 x 520.0 mm (37.40 x 5.47 x 20.47 inches)
Weight[2]
| Monitor With Stand | 9.2 kg (20.3 lbs) |
| Monitor Head Only | 6.3 kg (13.9 lbs) |
Packaging Weight
13.5 kg (29.8 lbs)
Mounting
Supports VESA mount 100 x 100 mm
Stand
Supports -5° to +23.5° tilt, left & right 45 swivel, -90° to +90° pivot, up to 155mm lift
In the Box
- Monitor with stand
- 1x DP 1.4 cable (1.8m)
- 1x USB-C® to USB-C® Gen 2 cable (1.5m)
- 1x Power cable (1.8m)
- ThinkVision® VoIP Stack MC60 monitor webcam (For models 64B0ZAT1 and 64B0ZAR1)
- Quick setup guide
- Warranty booklet
Notes:
| [1] The system dimensions may vary depending on configurations.Feature Default |
| [2] The system weight is approximate and based on results in Lenovo® lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.Feature Default |
Network
Ethernet
Gigabit Ethernet, 1x RJ-45
Ports[1]
Rear Ports[2]
- 1x USB-C® (USB 10Gbps / USB 3.2 Gen 2) with USB PD 3.0 100W and DisplayPort™ 1.4 Alt Mode HBR3, USB upstream[3]
- 1x USB-C® (USB 5Gbps / USB 3.2 Gen 1) with 15W PD, data transfer only, USB downstream
- 3x USB-A (USB 5Gbps / USB 3.2 Gen 1, 1x BC 1.2), USB downstream
- 1x HDMI® 2.1 TMDS, supports 3840x2160@60Hz
- 1x DisplayPort™ 1.4 (HBR3), supports max.bandwidth 32.4Gbps
Notes:
| [1] The transfer speed of following ports will vary and, depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed.
USB 2.0: 480 Mbit/s;
USB 3.2 Gen 1 (SuperSpeed USB 5Gbps, formerly USB 3.0 / USB 3.1 Gen 1): 5 Gbit/s;
USB 3.2 Gen 2 (SuperSpeed USB 10Gbps, formerly USB 3.1 Gen 2): 10 Gbit/s;
USB4® 20Gbps / USB 3.2 Gen 2x2 (SuperSpeed USB 20Gbps): 20 Gbit/s;
USB4® 40Gbps (USB 40Gbps): 40 Gbit/s;
Thunderbolt™ 3/4: 40 Gbit/s.StructureLevel2 |
| [2] Listed are maximum capacity of power delivery. Actual capacity of power delivery may vary depending upon devices connected or monitor configuration, and may decline with downstream USB ports connected or higher brightness setting.Product |
| [3] The output rating (100W, 20V/5A) is based on Lenovo®'s proprietary VDM technology. It is required to connect to products that support Lenovo® VDM to reach maximum power output. Actual power output may vary and may be lower.FeatureValue |
Security
Physical Locks
Kensington® Nano Security Slot™ (2.5 mm x 6 mm)
