Panel
Panel
Vertical Alignment (VA)
Max View Area
WxH: 1209.6 x 680.4 mm
Pixel Pitch
0.315 x 0.315 mm
Dot / Pixel Per Inch
80 dpi
Contrast Ratio
Contrast Ratio: 5000:1
View Angle (H / V)
Horizontal: 178°, Vertical: 178°
Color Gamut
72% NTSC (CIE 1931)
Color Support
1.07 Billion
Color Depth
10-bit (8-bit+FRC)
Screen Surface Treatment
Anti-glare
Operating System
Operating System
- Windows® 11 Support
- Windows® 10 Support
Multi-Media
Camera
No bundled webcam (Support MC80L Gen2, sold separately)
Speakers
Integrated Speakers, 2x 10W.
Support ThinkSmart® Bar 180, sold separately
Power Supply
Power Consumption
- Sleep / Off mode: <0.5W
- Switch-off Mode: <0.3W
- Internal Power Supply
- Energy Star Power On: 84W
- Energy Star TEC: 123kWh
- Typical / Max: 100W / 300W
Voltage Required
AC 100 to 240 V (50-60Hz)
Special Features
Special Features
- HDR10 Compliance
- Picture In Picture (PIP) / Picture By Picture (PBP) Support
- Lenovo® ThinkColour (Lenovo® Accessories and Display Manager) Support
Lenovo® ThinkColour supports Windows® 10 & 11, Mac OS (functions vary across systems).
Lenovo® Accessories and Display Manager is formerly Lenovo® Display Control Center.
- Brightness Calibration
- KVM Switch
- Natural Low Blue Light
- Smart Power
The Smart Power function intelligently detects overall power consumption and dynamically manages the power delivery to each device
Mechanical
Bezel Width
- Side: 3.3mm
- Bottom: 18.9mm
- Top: 2.6mm
Dimensions (WxDxH)[1]
1227 x 125 x 720.6 mm (48.31 x 4.92 x 28.37 inches)
Packaging Dimensions (WxDxH)
1370 x 185 x 850 mm (53.94 x 7.28 x 33.46 inches)
Weight[2]
17.9 kg (39.5 lbs.)
Packaging Weight
22.7 kg (50.1 lbs)
Mounting
Supports VESA mount 300 x 300 mm
Stand
Supports 0.1° to 5° tilt
In the Box
- 1x USB-C® to USB-C® Cable (3m, 5Gbps)
- 1x Power Cord for Adapter (1m)
- 1x Power Cord (2.8m)
- 7x Screws
- 1x Screwdriver
- 2x Cable clip
- 2x Washer
- Remote controller battery
- Remote controller
- Wall Mount Bracket
- Quick Setup Guide
Notes:
| [1] The system dimensions may vary depending on configurations.Feature Default |
| [2] The system weight is approximate and based on results in Lenovo® lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.Feature Default |
Network
Ethernet
Gigabit Ethernet, 1x RJ-45
Ports[1]
Rear Ports
- 1x USB-C® (USB 5Gbps / USB 3.2 Gen 1) with 15W PD, data transfer only, USB downstream
- 1x USB-B (USB 5Gbps / USB 3.2 Gen 1), USB upstream
- 2x HDMI® 2.1 TMDS
- 1x DisplayPort™ 1.4
- 1x DisplayPort™ 1.4 (Out)
- 1x serial (9-pin, RS232)
- 1x audio-out (3.5mm)
- 1x USB-C® (USB 5Gbps / USB 3.2 Gen 1) with USB PD 3.1 96W and DisplayPort™ 1.4 Alt Mode HBR3, USB upstream
- 4x USB-A (USB 5Gbps / USB 3.2 Gen 1), USB downstream
Notes:
| [1] The transfer speed of following ports will vary and, depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed.
USB 2.0: 480 Mbit/s;
USB 3.2 Gen 1 (SuperSpeed USB 5Gbps, formerly USB 3.0 / USB 3.1 Gen 1): 5 Gbit/s;
USB 3.2 Gen 2 (SuperSpeed USB 10Gbps, formerly USB 3.1 Gen 2): 10 Gbit/s;
USB4® 20Gbps / USB 3.2 Gen 2x2 (SuperSpeed USB 20Gbps): 20 Gbit/s;
USB4® 40Gbps (USB 40Gbps): 40 Gbit/s;
Thunderbolt™ 3/4: 40 Gbit/s.StructureLevel2 |
