Overview
| 1. | Nano-SIM card slot * | 5. | Kensington Nano Security Slot |
| 2. | SD Express 7.0 card reader | 6. | HDMI |
| 3. | Thunderbolt 4 | 7. | 2x Thunderbolt 5 |
| 4. | USB-A (USB 10Gbps), Always On | 8. | Headphone / microphone combo jack (3.5mm) |
Notes:
- Items with * are only available on selected models
Performance
Processor
Processor Family
Intel® H Series Core Ultra 7 / 9 / X7 / X9 Processor (Series 3); supports up to 16 cores; up to 5.1GHz
Processor
| Processor Name | Cores | Threads | Base Frequency | Max Frequency | Cache | Processor Graphics | NPU | Intel® vPro® Eligibility |
| Core Ultra 7 356H | 16 (4 P-core + 8 E-core + 4 LP E-core) | 16 | P-core 1.9GHz / E-core 1.5GHz / LP E-core 1.5GHz | P-core 4.7GHz / E-core 3.5GHz / LP E-core 3.3GHz | 18MB Intel® Smart Cache | Intel® Graphics, up to 40 TOPS | Up to 50 TOPS | - |
| Core Ultra 7 366H | 16 (4 P-core + 8 E-core + 4 LP E-core) | 16 | P-core 2.0GHz / E-core 1.6GHz / LP E-core 1.6GHz | P-core 4.8GHz / E-core 3.6GHz / LP E-core 3.4GHz | 18MB Intel® Smart Cache | Intel® Graphics, up to 40 TOPS | Up to 50 TOPS | Intel® vPro® Platform |
| Core Ultra 9 386H | 16 (4 P-core + 8 E-core + 4 LP E-core) | 16 | P-core 2.1GHz / E-core 1.6GHz / LP E-core 1.6GHz | P-core 4.9GHz / E-core 3.7GHz / LP E-core 3.5GHz | 18MB Intel® Smart Cache | Intel® Graphics, up to 40 TOPS | Up to 50 TOPS | Intel® vPro® Platform |
| Core Ultra X7 368H | 16 (4 P-core + 8 E-core + 4 LP E-core) | 16 | P-core 2.0GHz / E-core 1.6GHz / LP E-core 1.6GHz | P-core 5.0GHz / E-core 3.8GHz / LP E-core 3.6GHz | 18MB Intel® Smart Cache | Intel® Arc™ B390 GPU, up to 122 TOPS | Up to 50 TOPS | Intel® vPro® Platform |
| Core Ultra X9 388H | 16 (4 P-core + 8 E-core + 4 LP E-core) | 16 | P-core 2.1GHz / E-core 1.6GHz / LP E-core 1.6GHz | P-core 5.1GHz / E-core 3.8GHz / LP E-core 3.7GHz | 18MB Intel® Smart Cache | Intel® Arc™ B390 GPU, up to 122 TOPS | Up to 50 TOPS | Intel® vPro® Platform |
AI (Artificial Intelligence)
Operating System
Operating System
- Windows® 11 Pro
- Windows® 11 Home
- Fedora Linux
- Ubuntu Linux LTS
- Red Hat Enterprise Linux 10.2 (certified only, for detailed and latest information, please visit Red Hat Certified Hardware)
Graphics
Graphics
| Graphics | Type | Memory | AI TOPS (Peak) |
| Intel® Arc™ B390 GPU | Integrated | Shared | 122 TOPS (Int8) |
| NVIDIA® RTX PRO 1000 Blackwell Generation 8GB GDDR7 Laptop GPU | Discrete | 8GB GDDR7 | 440 TOPS (FP4 TOPS with Sparsity) |
| NVIDIA® RTX PRO 2000 Blackwell Generation 8GB GDDR7 Laptop GPU | Discrete | 8GB GDDR7 | 572 TOPS (FP4 TOPS with Sparsity) |
Monitor Support
Monitor Support
Supports up to 4 independent displays (native display and 3 external monitors via Thunderbolt™ 5, Thunderbolt™ 4, and HDMI®).
Max resolution for multiple external display:
• 3x 5210x3200@60Hz (Thunderbolt™ 5 and Thunderbolt™ 4)
• 1x 3840x2160@60Hz (HDMI®)
Max resolution for single external display:
• Thunderbolt™ 4 supports up to 7680x4320@60Hz or 3840x2160@240Hz
• Thunderbolt™ 5 supports up to 7680x4320@60Hz or 3840x2160@240Hz
• HDMI® supports up to 7680x4320@60Hz or 3840x2160@240Hz
Chipset
Memory
Memory Type
LPDDR5X-8533, maximum transfer speeds of up to 8533 MT/s;
16GB / 32GB / 64GB / 96GB memory modules are available
Storage
Storage Type
| Disk Type | Interface | Offering | Security |
| M.2 2280 SSD | PCIe® NVMe®, PCIe® 4.0 x4 | 512GB / 1TB | Opal 2.0 |
| M.2 2280 SSD | PCIe® NVMe®, PCIe® 5.0 x4 Performance[5] | 512GB / 1TB / 2TB / 4TB | Opal 2.0 |
Notes:
| [1] The storage capacity supported is based on the test results with current Lenovo® storage offerings.Classification Default |
| [2], [4] WWAN module occupies M.2 PCIe® 4.0 x4 slot, WWAN models support one M.2 SSD.FeatureValue |
| [3] The actual data transfer rate of the following PCIe® interface also depends on the capabilities of the connected PCIe® device. The listed values represent theoretical maximums. PCIe® 3.0 (x2 / x4): 2 GB/s (16 Gbps) / 4 GB/s (32 Gbps); PCIe® 4.0 (x2 / x4): 4 GB/s (32 Gbps) / 8 GB/s (64 Gbps); PCIe® 5.0 (x2 / x4): 8 GB/s (64 Gbps) / 16 GB/s (128 Gbps).Classification Default |
| [5] Gen 5 SSD on M.2 PCIe® 4.0 slot will run on PCIe® 4.0 protocols.FeatureValue |
Removable Storage
Multi-Media
Speakers
Stereo speakers:
• WLAN model: Dual speakers 2W x2, Dolby Atmos®
• WWAN model: Quad speakers (2W x2 + 1W x2), Dolby Atmos®
Camera
- 5.0MP + IR, with privacy shutter, fixed focus, Computer Vision Human Presence Detection on Image Signal Processor (ISP), temporal noise reduction
- No camera (for special bid model)
Battery
Power Adapter
Power Adapter[1]
- 140W USB-C® GaN (3-pin) AC adapter, supports PD 3.1, 100-240V, 50-60Hz
- No power adapter
Notes:
| [1] AC adapter offerings depend on the country.Classification Default |
Design
Display
Display
| Size | Resolution | Touch | Type | Brightness | Surface | Aspect Ratio | Contrast Ratio | Color Gamut | Refresh Rate | Viewing Angle (L/R/U/D) | Key Features |
| 16" | WUXGA (1920x1200) | Non-touch | IPS | 500nits | Anti-glare | 16:10 | 1200:1 | 100% sRGB | 60Hz | 89° / 89° / 89° / 89° | 91.7% screen to body ratio, X-Rite® Factory Color Calibration, Low power, TÜV Low Blue Light, Eyesafe® 2.0 Certified, DC dimming |
| 16" | WQUXGA (3840x2400) | Non-touch | IPS | 800nits | Anti-glare | 16:10 | 1500:1 | 100% DCI-P3 | 60Hz | 85° / 85° / 85° / 85° | 91.7% screen to body ratio, DisplayHDR™ 400, Dolby Vision®, Eyesafe® Certified 2.0, TÜV Low Blue Light, X-Rite® Factory Color Calibration, DC dimming |
| 16" | 3.2K (3200x2000) | Add-on Film Touch | Tandem OLED | SDR 600nits / HDR 1500nits (peak) | Anti-glare, anti-reflection, anti-smudge | 16:10 | 100,000:1 | 100% DCI-P3 | 40-120Hz VRR | 85° / 85° / 85° / 85° | 90.9% screen to body ratio, DisplayHDR™ 600, Dolby Vision®, Eyesafe® Certified 2.0, TÜV Low Blue Light, X-Rite® Factory Color Calibration, PWM dimming |
Input Device
Pen
- Lenovo® Yoga® Pen
- No pen bundled (purchase separately)
- No support (non-touch display doesn't support pen input)
UltraNav™
3-button TrackPoint® pointing device and glass surface multi-touch Haptic Touchpad, 85 x 135 mm (3.35 x 5.31 inches)
Mechanical
Dimensions (WxDxH)[1]
354.4 × 241.2 × 9.87 / 15.8 (front / rear), 20.6 (maximum) mm
13.95 × 9.50 × 0.39 / 0.62 (front / rear), 0.81 (maximum) inches
Notes:
| [1] The system dimensions may vary depending on configurations.Feature Default |
| [2] The system weight is approximate and based on results in Lenovo® lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.Feature Default |
Connectivity
Network
WLAN + Bluetooth®[1]
- Intel® Wi-Fi® 7 BE211, 802.11be 2x2 Wi-Fi® + Bluetooth® 5.4 (Bluetooth® 6.0 hardware ready)
- Intel® Wi-Fi® 7 BE211, 802.11be 2x2 Wi-Fi® + Bluetooth® 5.4 (Bluetooth® 6.0 hardware ready), Intel® vPro® technology support[2]
WWAN
- Wireless WAN upgradable to 5G (with antenna ready)
- Snapdragon® X61, 5G Sub-6 GHz, with embedded eSIM functionality
- No support
Notes:
| [1] Wi-Fi® operation (including Wi-Fi® 6, Wi-Fi® 6E, Wi-Fi® 7, etc.) is subject to the regulatory requirements of each country. Bluetooth® may operate at a lower version than hardware design depending on the factors such as operating system, driver, etc.Feature Default |
| [2] Intel® vPro® platform requires the hardware and software necessary to deliver the manageability use cases, security features, system performance, and stability that define the platform. For detailed vPro® support information, please refer to the System Management section.FeatureValue |
Ports[1]
Standard Ports
- 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), Always On
- 2x Thunderbolt™ 5, with USB PD 3.1 and DisplayPort™ 2.1, 140W input / 15W output
- 1x Thunderbolt™ 4, with DisplayPort™ 2.1 and USB PD 3.1, 140W input / 15W output
- 1x HDMI® 2.1, up to 8K/60Hz
- 1x Headphone / microphone combo jack (3.5mm)
- 1x SD Express 7.0 card reader
- 1x Kensington® Nano Security Slot™
Optional Ports
- 1x 2.5GbE RJ-45, via Lenovo® USB-C® to Ethernet Adapter (2.5Gbps)
- 1x Nano-SIM card slot (WWAN support models)
Notes:
| [1] The transfer speed of following ports will vary and, depending on many factors, such as the processing speed of the host device, file attributes and other factors related to system configuration and your operating environment, will be slower than theoretical speed. USB 2.0: 480 Mbit/s; USB 3.2 Gen 1 (SuperSpeed USB 5Gbps, formerly USB 3.0 / USB 3.1 Gen 1): 5 Gbit/s; USB 3.2 Gen 2 (SuperSpeed USB 10Gbps, formerly USB 3.1 Gen 2): 10 Gbit/s; USB4® 20Gbps / USB 3.2 Gen 2x2 (SuperSpeed USB 20Gbps): 20 Gbit/s; USB4® 40Gbps (USB 40Gbps): 40 Gbit/s; Thunderbolt™ 3/4: 40 Gbit/s. Thunderbolt™ 5: 80 Gbit/s (bidirectional), up to 120 Gbit/s in bandwidth boost mode for video-intensive applications.StructureLevel2 |
Security & Privacy
Manageability
System Management
Notes:
| [1] Intel® vPro® platform require an eligible Intel® processor, a supported operating system, Intel® LAN and/or WLAN silicon, firmware enhancements, and other hardware and software necessary to deliver the manageability use cases, security features, system performance, and stability that define the platform. See Intel® vPro® Platform for details.Product |
Service
Accessories
Operating Requirements
Operating Environment
Temperature[1]
- Operating: 5°C (41°F) to 35°C (95°F)
- Storage and transportation in original shipping packaging: -20°C (-4°F) to 60°C (140°F)
- Storage without package: 5°C (41°F) to 43°C (109°F)
Relative Humidity
- Operating: 8% to 95% at wet-bulb temperature 23°C (73°F)
- Storage and transportation: 5% to 95% at wet-bulb temperature 27°C (81°F)
Notes:
| [1] When you charge the battery, its temperature must be no lower than 10°C (50°F).Classification Default |
Environmental
Sustainability
Material[1]
90% Recycled Magnesium Aluminum C cover
75% Recycled Aluminum A cover
55% Recycled Aluminum D cover
90% PCC recycled plastic used in speaker enclosure
90% PCC recycled plastic used in the battery pack enclosure
50% PCC plastic D cover (Attached Internal Components)
90% PCC plastic 140W AC Adapter
46% Total PCC plastic
Plastic free packaging with 90% recycled and / or FSC certified content
Notes:
| [1] PCC: Post Consumer Content, recycled materials from customers.Classification Default |
Certifications
Green Certifications[1]
Green Certifications[2]
- ENERGY STAR® 9.0
- EPEAT™ Gold Registered
- RoHS compliant
- TCO Certified, generation 10
Notes:
| [1] The items listed under the "Green Certifications" section may not only refer to certification but also registration or self-declaration. For ESG & regulatory compliance documents, please visit https://compliance.lenovo.com.StructureLevel2 |
| [2] EPEAT™ registration and ENERGY STAR® certification are optional and only available on the models with preloaded OS. Please visit epeat.net and energystar.gov for more information.Classification Default |
Other Certifications
Other Certifications
- (Optional) Intel® Evo™ Platform
- Eyesafe® Certified 2.0
- TÜV Rheinland® Low Blue Light
ISV Certifications
ISV Certifications
Please visit ISV certifications for Lenovo® Workstations
- Lenovo reserves the right to change specifications or other product information without notice. Lenovo is not responsible for photographic or typographical errors. LENOVO PROVIDES THIS PUBLICATION "AS IS", WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions do not allow disclaimer of express or implied warranties in certain transactions, therefore this disclaimer may not apply to you.
- The specifications on this page may not be available in all regions, and may be changed or updated without notice.
