Processor
Processor Family
Intel® Core™ Ultra 5 / X7 Processor (Series 3)
Processor
| Core Ultra X7 368H | 16 (4 P-core + 8 E-core + 4 LP E-core) | 16 | P-core 2GHz / E-core 1.6GHz / LP E-core 1.6GHz | P-core 5GHz / E-core 3.8GHz / LP E-core 3.6GHz | 18MB Intel® Smart Cache | Intel® Arc™ B390 GPU, up to 122 TOPS | Up to 50 TOPS | Intel® vPro® Platform |
AI (Artificial Intelligence)
AI PC Category
Copilot+ PC
Operating System
Operating System**
- Windows® 11 Pro
- Windows® 11 Home
- No preload operating system
Graphics
Graphics**
| Intel® UHD Graphics | Integrated | Shared | - | 4096x2160@60Hz(HDMI®), 7680x4320@30Hz(Thunderbolt™ 4) | 1x HDMI® 2.1 TMDS, 1x Thunderbolt™ 4 | DirectX® 12 Ultimate |
| Intel® Arc™ B390 GPU | Integrated | Shared | 122 | 4096x2160@60Hz(HDMI®), 7680x4320@30Hz(Thunderbolt™ 4) | 1x HDMI® 2.1 TMDS, 1x Thunderbolt™ 4 | DirectX® 12 Ultimate |
Monitor Support
Monitor Support
Supports up to 3 independent displays via native display and 2 external monitor; supports external monitor via HDMI® and Thunderbolt™ 4
Chipset
Chipset
Intel® SoC (System on Chip) platform
Memory
Max Memory[1]
32GB soldered LPDDR5X-8533, not upgradable
Memory Slots
Memory soldered to systemboard, no slots, dual-channel
Notes:
| [1] The max memory is based on the test results with current Lenovo® memory offerings.Classification Default |
Storage
Max Storage Support[1]
Up to two drives, 2x M.2 SSD
• M.2 2280 SSD up to 2TB
Storage Type***
| M.2 2280 SSD | PCIe® NVMe®, PCIe® 4.0 x4 | Opal 2.0 |
| M.2 2280 SSD | PCIe® NVMe®, PCIe® 5.0 x4 | Opal 2.0 |
Notes:
| [1] The max capacity of each disk type is based on the test results with current Lenovo® storage offerings.Classification Default |
Removable Storage
Card Reader
No card reader
Multi-Media
Audio Chip
High Definition (HD) Audio, Realtek® ALC3345S-CGT codec
Speakers
Stereo speakers, 5W x2 (woofers), 2W x2 (tweeters), Dolby Atmos®, harman/kardon brand
Microphone
- Quad-microphone array (integrated with camera), with AI sound pick up, noise suppression
- No microphone
Camera**
- 16.0MP + IR with privacy shutter (physical switch on/off), with AI capability
- 5.0MP + IR with privacy shutter (physical switch on/off)
- No camera
Power Supply
Power Supply
| 170W | Adapter | 90% | 100V - 240V |
Display
Display[1]
| 27" | QHD (2560x2880) | Non-touch | IPS | 300nits | Anti-glare | 16:18 | 98% DCI-P3 | 60Hz | 89° / 89° / 89° / 89° | 14ms response Time, 10.7 Billion color support, 10-bit (8-bit+FRC), low blue light, flicker free |
Notes:
| [1] IPS (in-plane switching) technology may refer to IPS, PLS, ADS, AHVA, AAS.Classification Default |
Input Device
Keyboard
- Euterpe Wireless Keyboard, luna grey
- No keyboard
Mouse
- Euterpe Wireless Mouse, Luna Grey
- No mouse
Mechanical
Form Factor
AIO (27 inches)
Dimensions (WxDxH)[1]
480.9 x 191 x 655 mm (189.3 x 75.2 x 257.9 inches)
Packaging Dimensions (WxDxH)
582 x 283 x 777 mm (229.1 x 111.4 x 305.9 inches)
Weight[2]
Around 7.76 kg (17.1 lbs)
Packaging Weight
Around 12.25 kg (27 lbs)
Expansion Slots
Three M.2 slots (one for WLAN, two for SSD)
Stand
Full function monitor stand, supports -5° to +16° tilt, left & right 45° swivel, 90° pivot, up to 70mm lift
Notes:
| [1] The system dimensions may vary depending on configurations.Feature Default |
| [2] The system weight is approximate and based on results in Lenovo® lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model.Feature Default |
Security
Security Chip
Discrete TPM 2.0, TCG certified
Physical Locks
Kensington® Nano Security Slot™, 2.5 x 6 mm
Chassis Intrusion Switch
- Chassis intrusion switch
- No chassis intrusion switch
BIOS Security
- Absolute persistence module
- Administrator password
- Boot sequence control
- Boot without keyboard and mouse
- Cover tamper detected
- Intel® BIOS guard
- Individual USB port disablement
- Hard disk password
- Power-on password
- Smart USB protection (allows keyboard / mouse only, blocks all storage devices)
- Secure boot
- Secure wipe
Sustainability
Material[1]
30% OBP bag
FSC carton
65% PCC ABS in chassis
95% PCC ABS in KB/mouse
Notes:
| [1] PCC: Post Consumer Content, recycled materials from customers.
PIC: Post Industry Content, recycled materials from internal factories.
EPE: Expanded Polyethylene.
OBP: Ocean Bound Plastic, reducing plastic spill into the sea.
FSC: Forest Stewardship Council.ProductLine Default |
Green Certifications[1]
Green Certifications
- (Optional) ENERGY STAR® 9.0
- (Optional) EPEAT™ Gold Registered
- ErP Lot 3/7
- GREENGUARD®
- Low Halogen
- RoHS compliant
- TCO Certified, generation 10
- TCO edge
Notes:
| [1] The items listed under the "Green Certifications" section may not only refer to certification but also registration or self-declaration. For ESG & regulatory compliance documents, please visit https://compliance.lenovo.com.StructureLevel2 |
Other Certifications
Other Certifications
- Anti-dust
- Dolby Atmos®
- Healthcare compliance: Part of IEC 60601-1 / IEC 60601-1-2
- IP55-compliant (front panel of front face only)
- Eyesafe® Certified 2.0
- SGS Performance Tested certification: Super Quiet@Hi-Performance Grade 1
- Spatial Voice Isolation and Ambient Noise Shielding (16M camera configuration only)
- TÜV Rheinland® Flicker Free
- TÜV Rheinland® Low Blue Light (Hardware Solution)
- Zoom Room Certification
Mil-Spec Test
MIL-STD-810H military test passed (Low Pressure [Altitude] 500.6, High Temperature 501.7, Low Temperature 502.7, Temperature Shock 503.7, Contamination by fluids 504.3, Solar Radiation 505.7, Humidity 507.6, Salt Fog 509.8, Blowing Dust 510.7, Vibration 514.8, Shock 516.8)
